TCXO振蕩器（溫度補償晶體振蕩器）是在一定溫度范圍內具有嚴格頻率偏移的振蕩器單元。典型的TCXO應用可以在溫度變化環境中需要穩定頻率的領域中找到。在TCXO中，晶體隨溫度的頻率變化由內部電路補償。這個TCXO溫控電路可以是模擬的，也可以是數字的。數字補償TCXO溫補晶振裝置通過頻率偏移特性進行“編程”。對于輸出信號，有幾種選擇。CMOS TCXO和削波正弦波TCXO是最常見的，但我們也可以選擇其他輸出電平，如真正的正弦波TCXO類型。可選的，幾種類型可以提供EFC（電子頻率控制）。這些VCTCXO振蕩器（壓控TCXO）類型可以通過控制電壓來調節頻率。封裝類型從小型4焊盤SMD TCXO單元到通孔DIL14 TCXO外殼。

VCXO電壓控制晶體振蕩器

FCD-Tech壓控晶體振蕩器（VCXO振蕩器）產品組合提供多種封裝，包括SMD VCXO壓控晶體振蕩器類型和通孔VCXO壓控振蕩器類型。可用輸出邏輯：CMOS VCXO、LVPECL VCXO、LVDS VCXO、HCSL VCXO或真正弦波VCXO。低相位噪聲、低抖動、牽引范圍和溫度容差的各種規格特性。

晶體濾波器- MCF -帶通晶體濾波器-單邊帶晶體濾波器

FCD-Tech提供全系列晶體濾波器。我們有可能為商業、軍事和空間應用提供定制設計的晶體濾波器類型。

射頻和微波產品

我們作為模塊或用于19英寸標準機架的射頻和微波產品。重點是工作在L、S、C、X、Ku頻段的產品，用于衛星通信、雷達系統（氣象、國防、民用）、發射機/接收機、WIMAX等應用。

所有器件均符合RoHS標準

Model	Frequency Range Mode of operation	Size	Features
Model	Frequency Range Mode of operation	Size	Features	F1612A	24 - 60 MHz Fundamental	1.6 x 1.2 x 0.40 mm	Ultra miniature 4 pad SMD package Very Low Ageing Excellent heat resistance and shock resistance Frequency range 24MHz to 60MHz (fundamental mode) Applications: Bluetooth, Wireless Applications,...
F1612AS	24 - 60 MHz Fundamental	1.6 x 1.2 x 0.35 mm	Ultra miniature 4 pad SMD package Ultra thin thickness 0.35mm Excellent heat resistance and shock resistance Frequency range 24MHz to 60MHz (fundamental mode) Options for initial stability and temperature tolerance Applications: Bluetooth, Wireless Applications,...
F2016A	16 MHz ~ 60 MHz Fundamental	2.0 x 1.6 x 0.45 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board Excellent heat resistance and shock resistance Frequency range 16 MHz - 60 MHz (fundamental mode) Options for initial stability and temperature tolerance Applications : Bluetooth, Wireless applications, Mobile Phones, ...
F2520A	12 - 80 MHz Fundamental	2.5 x 2.0 x 0.55 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board Excellent heat resistance and shock resistance Frequency range 12 MHz - 80 MHz (fundamental mode) Options for initial tolerance and temperature stability Applications: Bluetooth, Wireless Applications, Modems, ...
F3225A	10 - 60 MHz Fundamental 60 - 156.250 MHz 3rd overtone	3.2 x 2.5 x 0.65 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board Low impedance performance Frequency range 10MHz - 156.25 MHz Options for initial tolerance and temperature stability Applications: Bluetooth, Wireless Applications, GPS, ...
F4025A	12 - 60 MHz Fundamental	4.0 x 2.5 x 0.75 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board Low impedance performance Frequency range 12MHz - 60MHz Options for initial tolerance and temperature stability Applications: Test Equipment, Wireless Applications, Modems, .. .
F5032A	7.6 MHz ~ 54.0 MHz Fundamental 40.0 MHz ~ 156.250 MHz 3rd-overtone	5.0 x 3.2 x 0.8 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board High resolution frequency tolerance is obtained Frequency range 7.6MHz - 156.25 MHz Options for initial tolerance and temperature stability Applications: Bluetooth, Wireless Applications, Mobile phones, ...
F5032B	7.6 MHz ~ 54.0 MHz Fundamental 40.0 MHz ~ 156.250 MHz 3rd-overtone	5.0 x 3.2 x 1.2 mm	Ultra thin and miniature 2 pad SMD Crystal package Completely sealed type with metal case sealed on ceramic board High resolution frequency tolerance is obtained Frequency range 7.6MHz - 156.25 MHz Options for initial tolerance and temperature stability Applications: Bluetooth, Wireless Applications, Mobile phones, ...
F6035A	7.0 MHz ~ 54.0 MHz Fundamental 40.0 MHz ~ 200.0 MHz 3rd-overtone	6.0 x 3.5 x 1.0 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board High resolution frequency tolerance is obtained Frequency range 7.0MHz - 200MHz Options for initial tolerance and temperature stability Applications: PDA, Computer, Microprocessors, ...
F7050A	6.0 MHz ~ 40.0 MHz Fundamental 40.0 MHz ~ 70.0 MHz 3rd-overtone	7.0 x 5.0 x 1.0 mm	Ultra thin and miniature 4 pad SMD package Completely sealed type with metal case sealed on ceramic board High resolution frequency tolerance is obtained Frequency range 6.0MHz - 70MHz Options for initial tolerance and temperature stability Applications: PDA, Computer, Modem, Communication, ...
HC49-US SMD	3.0 MHz ~ 54.0 MHz Fundamental /AT-cut 36.0 MHz ~ 150.0 MHz 3rd-overtone /AT-cut	11.4 x 4.7 x 4.5 mm	Metal welded package, 2 pad SMD Crystal HC49-US High resolution frequency tolerance is obtained Frequency range 3.0MHz - 150MHz Options for initial tolerance and temperature stability Height 2.5mm available Applications: Computers, Microprocessor, Modem, ...
HC49-U Gull Wing SMD Crystal	1.8432 MHz ~ 48.0 MHz Fundamental 26.0 MHz ~ 90.0 MHz 3rd-overtone 80.0 MHz ~ 176.0 MHz 5th-overtone	HC49/U SMD 11 x 4.7 x 13.5mm HC49/T SMD 11 x 4.7 x 11.3mm	SMD Gull WIng (Metal Jacked) HC49-U Crystal package High Precision available Wide Frequency Range Standard size HC49-U (13.5mm heigt) and shorter version HC49-T (11mm) Applications: Telecommunication equipment, ...
UM-4, UM-5, UM-1 SMD Crystal Gull Wing	10.0 MHz ~ 45.0 MHz Fundamental 35.0 MHz ~ 200.0 MHz 3rd / 5th overtone	8.0 x 7.8 x 3.5 mm	SMD Gull Wing (Metal Jacket) UM-1, UM-4, UM-5 Crystal Package High resolution frequency tolerance is obtained Frequency range 10.0MHz - 200MHz Options for initial tolerance and temperature stability Height 8mm (UM-1), 6mm (UM-5), 4.3mm (UM-4) Applications: Telecommunication equipment, ...

Type	Model	Frequency Range	Size	Features
Type	Model	Frequency Range	Size	Features	CMOS Oscillator	SX1C	1.5 – 80.0 MHz	2.0 x 1.6 x 0.7 mm	Smallest industry SMD crystal oscillator package High shock and vibrational resistivity oscillator Applications: Telecommunications, Portable electronics, …
CMOS Oscillator	SX2CB	1.5 – 54.0 MHz	2.5 x 2.0 x 0.8 mm	Ultra-miniature SMD crystal oscillator package Low voltage High shock and vibrational resistivity Applications: Telecommunications, Portable electronics,…
CMOS Oscillator	SX2C	1.5 – 133.0 MHz	2.5 x 2.0 x 0.9 mm	Ultra SMALL SMD crystal oscillator package Tight Stability available Excellent heat resistance and shock resistance oscillator Applications: Bluetooth, Wireless Applications, Modems, ...
CMOS Oscillator	SX2CG	2.5 – 55.0 MHz	2.5 x 2.0 x 0.9 mm	Ultra-miniature SMD crystal oscillator package Industrial grade tight temperature stability available ( +-10 ppm -40/+85°C ) Low phase noise oscillator Applications: Wireless LAN, Home networking, mobile communications,…
CMOS Oscillator	SX3CB	1.5 – 54.0 MHz	3.2 x 2.5 x 1.1 mm	Ultra-miniature SMD crystal oscillator package Low voltage Low current Applications: Wireless communications, Portable electronics, Fibre Channel,…
CMOS Oscillator	SX3C	1.0 – 133.0 MHz	3.2 x 2.5 x 1.2 mm	Ultra-miniature SMD crystal oscillator package High shock and vibrational resistivity Low current consumption Applications: Wireless communications, Portable electronics,...
CMOS Oscillator	SX3CG	2.5 – 55.0 MHz	3.2 x 2.5 x 0.9 mm	Ultra-miniature SMD crystal oscillator package Industrial grade tight temperature stability available ( +-10 ppm -40/+85°C ) Low Phase noise oscillator Applications: Wireless LAN, Home networking, mobile communications,…
CMOS Oscillator	SX5CB	1.0 – 125.0 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package Low voltage Low current Applications: Bluetooth , Portable electronics, Wireless LAN …
CMOS Oscillator	SX5C	1.0 – 133.0 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package High shock and vibrational resistivity Many options available Applications: Wireless communications, Portable electronics,…
CMOS Oscillator	SX5CG	2.5 – 55.0 MHz	5.0 x 3.2 x 1.05 mm	Miniature SMD crystal oscillator package Industrial grade tight temperature stability available ( +-10 ppm -40/+85°C ) Low phase noise and jitter clock oscillator Applications: Wireless LAN, Home networking, mobile communications, …
CMOS Oscillator	SX5CL	0.5 – 50 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package Ultra low current consumption Applications: Hand-held consumer electronics
CMOS Oscillator	SX7CB	0.5 – 160.0 MHz	7.0 x 5.0 x 1.4 mm	SMD crystal oscillator package Low voltage Low current Applications : PC main boards, Portable electronics, Wireless LAN....
CMOS Oscillator	SX7C	0.5 – 165 MHz	7.0 x 5.0 x 1.4 mm	SMD crystal oscillator package High output drive capability applications Many options available Applications : Wireless communications, PC main boards, ......
CMOS Oscillator	SX7CF	125.0 – 320.0 MHz	7.0 x 5.0 x 1.8 mm	SMD crystal oscillator Phase jitter less then 0.5 ps Applications:Optical, SONET, xDSL, SDH,....
CMOS Oscillator	SX7CW	125.0 – 800.0 MHz	7.0 x 5.0 x 1.8 mm	SMD crystal oscillator Multiplier circuit, PLL design High frequency available Applications : Optical, SONET, xDSL, SDH.....
CMOS Oscillator	SX7CL	0.25 – 50.0 MHz	7.0 x 5.0 x 1.4 mm	SMD crystal oscillator package Ultra low current consumption Applications : Hand-held consumer electronics
CMOS Oscillator	SP1C	1.0 – 200.0 MHz	14.0 x 9.8 x 4.7 mm	Plastic molded SMD crystal oscillator J-lead terminals Applications: Clock signals for microprocessors, Telecommunication equipment, …
CMOS Oscillator	DLHC	1.0 – 200.0 MHz	12.7 x 12.7 x 5.08 mm 12.7 x 12.7 x 7.48 mm	Through hole DIL8 oscillator - CMOS Low Phase Noise Tight Tolerances Applications: Microprocessors, Digital circuit,…
CMOS Oscillator	DLC	1.0 – 800.0 MHz	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.48 mm	Through hole DIL14 oscillator - CMOS Low Phase Noise Tight Tolerances Applications: Base stations, Test equipment, Synthesizers
LVPECL Oscillator	SX3EK	13.5 - 200 MHz	3.2 x 2.5 x 1.0 mm	Miniature SMD crystal oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box,...
LVPECL Oscillator	SX5EK	13.5 - 200 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box,...
LVPECL Oscillator	SX7EK	13.5 - 200 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator - 6pin Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box,...
LVPECL Oscillator	SX7EF	38 - 640 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator 6 pin package Low jitter multiplier circuit Application : SONET, xDSL, SDH, Set-top box,...
LVPECL Oscillator	SX7EW	1 - 800 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator package Moderate jitter at low cost Multiplier circuit, PLL design Applications : SONET, xDSL, Video,....
LVPECL Oscillator	DLE	0.75 - 800 MHz	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.48 mm	Through hole DIL14 oscillator package Reduced jitter design without PLL and multiplier circuit Many options available Applications : SONET, xDSL,SDH, Set-top box,...
LVDS Oscillator	SX3LK	13.5 - 200 MHz	3.2 x 2.5 x 1.0 mm	Miniature SMD crystal oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box,...
LVDS Oscillator	SX5LK	13.5 - 200 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box,...
LVDS Oscillator	SX7LK	13.5 - 200 MHz	7.0 x 5.0 x 1.8 mm	SMD Miniature SMD oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Applications : SONET, xDSL, SDH, Set-top box
LVDS Oscillator	SX7LW	1 - 800 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator package Moderate jitter at low cost Multiplier circuit, PLL design Applications : SONET, xDSL, Video...
LVDS Oscillator	SX7LF	38 - 640 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator package Low jitter multiplier circiut Applications : SONET, xDSL, SDH, Set-top box,...
LVDS Oscillator	DLL	0.75 - 800 MHz	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.48 mm	Through hole DIL14 crystal oscillator package Reduced jitter design without PLL and multiplier circuit Superior phase noise Many options availabe Applications : SONET, xDSL, SDH, Set-top box, ...
HCSL Oscillator	SX3HK	13.5 - 200 MHz	3.2 x 2.5 x 1.0 mm	Miniature SMD crystal oscillator package Excellent Phase Noise Extremely low current consumption Applications : SONET, xDSL, SDH, Media box,...
HCSL Oscillator	SX5HK	13.5 - 200 MHz	5.0 x 3.2 x 1.2 mm	Miniature SMD crystal oscillator package Excellent Phase Noise Extremely low current consumption Applications : SONET, xDSL, SDH, Media box,...
HCSL Oscillator	SX7HK	13.5 - 200 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator package Excellent Phase Noise Extremely low current consumption Applications : SONET, xDSL, SDH, Media box,...
HCSL Oscillator	DLH	25 - 200 MHz	20.7 x 13.1 x 5.08 mm 20.7 x 13.1 x 7.48 mm	Through hole DIL14 oscillator package Excellent Phase Noise Many options available Applications : SONET, xDSL, SDH, Media box,...
True Sine Wave Oscillator	SX5SR	10 - 52 MHz	5.0 x 3.2 x 1.2 mm	Standard miniature SMD crystal oscillator package High purity and low total harmonic distortion. Applications : Audio modulation
True Sine Wave Oscillator	SX7SR	10 - 52 MHz	7.0 x 5.0 x 1.8 mm	Miniature SMD crystal oscillator package High purity and low total harmonic distortion. Applications : Audio modulation
True Sine Wave Oscillator	DLS	10 - 800 MHz	20.4 x 12.9 x 5.08 mm	Through hole DIL14 crystal oscillator package High purity and low total harmonic distortion. Applications : Audio modulation
32.768KHz Oscillator	SX2K	32.768 KHz	2.5 x 2.0 x 0.8 mm	Ultra-miniature 32.768KHz SMD oscillator package Low current consumption Extend temperature range available Applications: Wireless LAN, Bluetooth and mobile communication,…
32.768KHz Oscillator	SX2KL	32.768 KHz	2.5 x 2.0 x 0.8 mm	Ultra-miniature 32.768KHz SMD oscillator package High shock/vibration resistance (semi-conductor process) Extend temperature range available, very quick start-up Custom make Frequency 0.5 Hz to 500 MHz Applications: Portable electronics,…
32.768KHz Clock Oscillator	SX3K	32.768 KHz	3.2 x 2.5 x 1.1 mm	Miniature 32.768KHz SMD oscillator package Low current consumption Extend temperature range available Applications: Wireless LAN, Bluetooth and mobile communication,…
32.768KHz Clock Oscillator	SX3KL	32.768 KHz	3.2 x 2.5 x 1.1 mm	Ultra miniature 32.768KHz SMD oscillator package Featured by tuning fork crystal Ultra low µA current consumption Applications: Portable field communication, Electricity-gas-water metering,…
32.768KHz Clock Oscillator	SX5K	32.768 KHz	5.0 x 3.2 x 1.2 mm	Miniature 32.768KHz SMD oscillator package Low current consumption Extend temperature range available Applications: Wireless LAN, Bluetooth and mobile communication,…
32.768KHz Clock Oscillator	SX7K	32.768 KHz	7.0 x 5.0 x 1.4 mm	Miniature 32.768KHz oscillator package Low current consumption Extend temperature range available Applications: Wireless LAN, Bluetooth and mobile communication,…
